The SG05P+1SFP-65WS is an unmanaged 5 Port 10/100/1000M PoE+1SFP Solar & Battery powered POE switch integrating solar power generation, intelligent POE power supply and full-automatic charge and discharge control.
It is a great solution for reliably powering both 802.3af/at and passive POE devices in remote areas where there is either no grid power source (off grid) or the grid power source is unreliable.
It supports full-automatic charging and discharging function, with a maximum charging current of 5A The advanced PWM intelligent charging system greatly improves the efficiency of photovoltaic power generation It supports two battery types: lead-acid battery and lithium battery.
There are 6 built-in battery specifications, and the maximum capacity is 50AH Support 12V / 24V (maximum 400W) solar panel input Using independent intelligent PSE power supply chip Port 1 support 802.3af/at POE+ 60W Port 2-3 support 802.3af/at Port 4-5 support 802.3af/at & Passive POE (auto detect) Support POE power supply output with total power up to 65W Adopt Realtek's latest intelligent network CPU Application example of operator base station Schematic diagram of switch connection
1.3" LCM color touchscreen with AR switch management,
24x 10GbE RJ45 ports and 2x 25G SFP28 ports
PLEASE NOTE - By default, for powered items, Ubiquiti includes adapter plugs that are not suited for South Africa. In these cases, the wrong adapter plug will carefully be removed from the box and a South African compatible plug will be sent separately.
