Smart 2Ch Relay Switch 10A + Shell | RF433Mhz + BT | DC 7‑32V Input

GW-T-Smart 2Ch Relay Switch-Tuya DC 7‑32V
>Get registered and you will earn 3 points Get registered and you will earn 3 points (Each R100 spent = 1 point).
Your cart will total 3 points.
  • Power Input: DC 7–32 V (ideal for 12 V / 24 V systems, batteries & solar setups)
  • Channels: 2 independent relay outputs
  • Relay Rating: Up to 10 A per channel
  • Contacts: Dry contact (COM / NO / NC) for flexible wiring
  • Connectivity: Wi-Fi 2.4 GHz + Bluetooth
  • RF Support: 433 MHz RF remote compatible (remote not included)
  • App Control: Tuya Smart / Smart Life app (iOS & Android)
  • Voice Control: Works with Google Assistant & Amazon Alexa
  • Control Modes: Self-locking (ON/OFF) & Inching (momentary)
  • Remote Access: Control from anywhere via smartphone
  • Automation: Timers, schedules, scenes & smart routines
  • Manual Control: On-board buttons for direct switching
  • Indicators: LED status lights for each channel
  • Design: Compact PCB with protective shell
  • Use Cases: DC lighting, motors, gates, garage doors, pumps, DIY automation
  • Installation: Suitable for low-voltage DC applications
  • What’s Included: 2-Channel smart relay module + enclosure
R265 incl. VAT
R231 excl. VAT

IN STOCK at GeeWiz!
If ordered before 4PM:
DELIVERED next business day (main centres)
or 3-5 days (regional areas OR large/heavy packages)
COLLECTION from GeeWiz available SAME DAY
Also available for in-store purchase during business hours!

Or as low as R89 over 6 months interest-free, using your existing credit card. How it works

Volume discounts

Quantity Price You Save
5 R260 2%
10 R255 4%
151+ click to email

Quantity

A compact smart relay controller with 2 independent channels that lets you switch electrical loads using Wi-Fi (Tuya SmartLife app), Bluetooth, or RF 433 MHz remote control (remote sold separately). Designed for DIY automation projects and smart home installations.

This DC-powered option accepts 7–32 V DC supply, ideal for battery systems, solar setups, DC appliance switching, and low-voltage automation tasks.

Key Features

Power & Connectivity

  • Input Voltage (DC version): 7–32 V DC via terminal block — select this option when ordering.
  • Micro-USB 5 V DC input option also available for powering logic circuits.
  • Wi-Fi: Works on IEEE 802.11 b/g/n 2.4 GHz networks for remote control via the Tuya/SmartLife app.
  • Bluetooth Low Energy: Local control without internet.
  • RF 433 MHz support: Use with compatible remote controls (sold separately) for manual switching.

Smart Control

  • Control devices from your smartphone via the Tuya SmartLife app.
  • Compatible with Amazon Alexa and Google Home voice assistants.
  • Create schedules, timers, scenes, and automation routines.
  • Manual mode buttons on the board for direct switching.

Relay Outputs

  • 2 independent relay channels — each channel can switch a load.
  • Dry contact relays: switch external circuits without injecting power (relay contacts only).
  • Max switching load: AC up to 250 V, 10 A (for AC loads). DC up to 30 V, 10 A (for DC loads)

Mode Options

  • Self-locking (stay ON/OFF)
  • Inching (pulse/temporary ON) Selectable via board button or app configuration.

Physical

  • Compact PCB with protective shell
  • LED indicators for channel status
  • Operating range: –10 °C to +60 °C, 5–95 % humidity.

Typical Uses

  • Smart lighting control
  • Automate DC devices (12 V/24 V systems)
  • Gate or garage switches
  • Motor controls with external drivers
  • Timed or app-controlled appliances
  • Solar/battery-powered smart automation

Because the board presents dry contact outputs, you can use it safely with external loads and power sources appropriate to the load (e.g., separate DC battery for a motor) without passing supply through the board.

What’s in the Box

  • 1 × Smart 2Ch Relay Switch DC-powered version
  • 1 × Protective Shell
  • 1 × Quick Manual (RF remote not included)

Wiring & Installation Notes

  • Power: Connect a 7–32 V DC supply to the DC input terminals to power the logic and relays.
  • Outputs: Use the COM/NO/NC terminals for each channel as dry contacts — the board does not supply load power itself. You must provide appropriate external power (battery or DC supply) to your device.
  • Safety: Always disconnect power before wiring. This board does not include mains isolation, so use caution when switching high voltages.

Tips & Compatibility

  • Works with Android & iOS through the Tuya SmartLife app.
  • Ensure your Wi-Fi router broadcasts at 2.4 GHz (not 5 GHz).
  • Ideal for DC systems like 12 V or 24 V common in solar, automotive, and workshop applications.
