Shelly 1PM Gen3- World's Smallest Wi-Fi Relay Switch with Power Metering.
SHELLY 1PM GEN3
Get registered and you will earn 5 points
(Each R100 spent = 1 point).Your cart will total 5 points.
- Precise and real-time power metering with free cloud data storage for analysis and energy usage optimization
- New processor – ESP-Shelly-C38F chip with an increased memory of 8 MB
- Improved durability of terminals
- High security
- Wi-Fi range extender & Bluetooth gateway
- Supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates
- No HUB required! Easy control through Shelly Smart Control app, various home automation protocols, platforms, as well as voice assistants
- Supports KNXnet / IP communication
R476 incl. VAT
R414 excl. VAT
IN STOCK at EXTERNAL supplier.
If ordered before 10AM:
DELIVERED in 2-3 business days (main centres)
or 3-5 business days (regional areas or large items)
COLLECTION from GeeWiz available in 1-2 business days
Or as low as R159 over 6 months interest-free, using your existing credit card. How it works
Shelly 1PM Gen3 Wi-Fi Operated Smart Switch
Wi-Fi-operated smart switch, with power monitoring​
For remote control of a wide range of home appliances and office equipment.
- Precise and real-time power metering with free cloud data storage for analysis and energy usage optimization
- New processor – ESP-Shelly-C38F chip with an increased memory of 8 MB
- Improved durability of terminals
- High security
- Wi-Fi range extender & Bluetooth gateway
- Supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates
- No HUB required! Easy control through Shelly Smart Control app, various home automation protocols, platforms, as well as voice assistants
- Supports KNXnet / IP communication
Wi-Fi Operated
Connect Shelly 1PM Gen3 to your Wi-Fi network. No HUB required!
Bluetooth
Add devices quickly and easily via Bluetooth connection, using Shelly Cloud App.
Power Monitoring
Shelly 1PM Gen3 provides precise monitoring of power consumption.
Wide range of voltage support
Use it to control a wide range of devices and appliances.
Smart Schedules
Set custom schedules based on your daily agenda or follow the sunrise/sunset and control your lighting accordingly.
Smart Scenes
Set custom scenes by combining Shelly 1PM Gen3 with your other Shelly devices.
Specifications
- Size (HxWxD): 37x42x16
- Weight: 27g
- Screw terminals max torque: 0.4 Nm
- Conductor cross section: 0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules)
- Conductor stripped length: 6 to 7 mm
- Mounting: Wall console
- Shell material: Plastic
- Shell color: Red
- Terminal Color: Black
- Ambient working temperature: -20 °C to 40 °C
- Humidity: 30 % to 70 % RH
- Max. altitude: 2000m
Electrical
Power supply: 110-240 V~ / 24-30 V⎓
Power consumption: < 1.2 W
External protection: Cable protection switch in accordance with EN60898-1 (tripping characteristic B or C, max. 16 A rated current, min. 6 kA interrupting rating, energy limiting class 3)
Output circuits ratings
Max. switching voltage: 240 V~ / 30 V⎓
Max. switching current: 16A (240 V~) / 10A (30 V⎓)
Sensors, meters
Internal-temperature sensor: Yes
Voltmeter (AC): Yes
Ammeter (AC): Yes
Radio
Wi-Fi
Protocol: 802.11 b/g/n
RF band: 2401 - 2483 ÐœHz
Max. RF power: < 20 dBm
Range:Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)
Bluetooth
Protocol: 4.2 with BLE
RF band: 2400 - 2483.5 MHz
Max. RF power: < 4 dBm
Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)
Microcontroller unit
CPU: ESP-Shelly-C38F
Flash: 8MB
