- Z-Wave™ smart switch, 1 channel 16 A
- Dry contacts
- Extremely low power consumption: 0.3 W.
- Latest technology: Z-Wave 800 Series
- Z-Wave frequency band: 868.4 MHz (CEPT countries)
- Automatic set-up with SmartStart
- Security 2 Authenticated for the highest level of security
- Supports over-the-air firmware updates (OTA)
- Works with Z-Wave certified gateways and over 4,000 Z-Wave devices
- Z-Wave operated
Shelly Z-Wave Smart Switch With Dry Contacts Allows You To Connect Various Power Supply Loads To The Device
SHELLY WAVE 1
Get registered and you will earn 6 points
(Each R100 spent = 1 point).Your cart will total 6 points.
- Z-Wave™ smart switch, 1 channel 16 A
- Dry contacts
- Extremely low power consumption: 0.3 W.
- Latest technology: Z-Wave 800 Series
- Z-Wave frequency band: 868.4 MHz (CEPT countries)
- Automatic set-up with SmartStart
- Security 2 Authenticated for the highest level of security
- Supports over-the-air firmware updates (OTA)
- Works with Z-Wave certified gateways and over 4,000 Z-Wave devices
- Z-Wave operated
R625 incl. VAT
R544 excl. VAT
IN STOCK at EXTERNAL supplier.
If ordered before 10AM:
DELIVERED in 2-3 business days (main centres)
or 3-5 business days (regional areas or large items)
COLLECTION from GeeWiz available in 1-2 business days
Or as low as R209 over 6 months interest-free, using your existing credit card. How it works
Shelly Wave 1 Smart Switch
Z-Wave smart switch with dry contacts​.
Allows you to connect various power supply loads to the device, such as electrical locks, gates, garage doors, irrigation system, and lights.
- Z-Wave™ smart switch, 1 channel 16 A
- Dry contacts
- Extremely low power consumption: 0.3 W.
- Latest technology: Z-Wave 800 Series
- Z-Wave frequency band: 868.4 MHz (CEPT countries)
- Automatic set-up with SmartStart
- Security 2 Authenticated for the highest level of security
- Supports over-the-air firmware updates (OTA)
- Works with Z-Wave certified gateways and over 4,000 Z-Wave devices
Z-Wave operated
Connect Wave 1 to your Z-Wave network and control it remotely. It‘s compatible with all certified Z-Wave gateways.
Associations
Establish direct communication between devices in your Z-Wave local network and set custom actions with no hub present!
Dry contacts
Connect different power supply loads (up to 16A) to the device.
Wide range of voltage support
Use a wide range of output voltage levels. Supports low voltages.
Custom schedules
Create personalized schedules aligned with your daily routine or synchronize with sunrise/sunset to manage your lighting (gateway required).
Smart Scenes
Set custom scenes by combining Wave 1 with any other Z-wave devices(gateway required).
Specifications
- Power supply: 110-240 V AC / 24-48 V DC / 12 V DC ± 10%
- Power consumption: < 0.3 W
- Max. switching voltage AC: 240 V
- Max. switching current AC: 16 A
- Max. switching voltage DC: 30 V
- Max. switching current DC: 10 A
- Overheating protection: Yes
- Distance: Up to 40 m indoors (131 ft.) (depends on local condition)
- Z-Wave® repeater: Yes
- CPU: Z-Wave® S800
- Z-Wave® frequency band: 868,4 MHz
- Maximum radio frequency power transmitted in frequency band(s): < 25 mW
- Size (H x W x D): 37x42x16 ±0.5 mm / 1.46x1.65x0.63 ±0.02 in
- Weight: 26 g / 0.92 oz.
- Mounting: Wall console
- Screw terminals max. torque: 0.4 Nm / 3.5 lbin
- Conductor cross section: 0.5 to 1.5 mm² / 20 to 16 AWG
- Conductor stripped length: 5 to 6 mm / 0.20 to 0.24 in
- Shell material: Plastic
- Color: Blue
- Ambient temperature: -20°C to 40°C / -5°F to 105°F
- Humidity: 30% to 70% RH
- Max. altitude: 2000 m / 6562 ft
