RG-RAP6262(G) is a high-power outdoor omnidirectional dual-band access point provided by Ruijie Reyee for the scenarios such as villages, villas, parks, scenic spots, and squares.
It supports 802.11a/b/g/n/ac/ax.
The product can simultaneously work in the 2.4 GHz and 5 GHz frequency bands, support dual-band dual-stream MU-MIMO, and provide 2.4 GHz 574 Mbps and 5 GHz 1201 Mbps.
The entire device provides a maximum of 1775 Mbps access rate, and is equipped with built-in omnidirectional high-gain antennas.
The spherical structure design of RG-RAP6262(G) is smart and elegant, and the shell meets the IP68 protection grade, which is suitable for use in extreme outdoor environment and can effectively avoid the influence of bad weather and environment.
The separation mounting method greatly simplifies the installation and maintenance.
The RG-RAP6262(G) supports remote power over Ethernet (802.3at standard PoE) and local DC 12V power supply mode.
It has two GE ports, which can be directly connected to cameras or cascaded switches, greatly enriching outdoor networking solutions and applying to more scenarios.
As a Reyee access point, RG-RAP6262(G) supports the intelligent networking features of Reyee network.
It does not need a wireless controller and does not need to access the Internet.
The devices automatically discover each other, set up network, and complete configurations.
The Reyee network app helps you quickly complete network access, configurations, remote management, and remote maintenance on the device, greatly reducing the investment of device cost, labor cost and time cost in the process of wireless network construction.
You can also perform comprehensive local and remote management of the entire network devices by using app, Web, Ruijie Cloud, or Reyee Routers, or share with others for assistance management.
This makes the enterprise network simpler, easier-to-use, more secure and convenient.
With the rack-separated mounting design, the RG-RAP6262(G) can be installed by only two steps, which reduces the difficulty of overhead working.
Step 1: Fix the sheet metal bracket to the wall with expansion screws, or fix the sheet metal bracket to the pole with a clamp.
Step 2: Insert the device and connecting rod into the slot of the sheet metal bracket, and fix them with screws.
The RG-RAP6262(G) supports remote power over Ethernet (802.3at standard PoE) and local DC 12 Vpower supply.
The device can connect to both the power supplies at the same time as power backup, to avoid power failures caused by lightning damage and greatly improve the reliability of outdoor operation.
The RG-RAP6262(G) has two GE ports, which can be connected to cameras and switches.
The two ports greatly enrich the outdoor networking modes and apply to more scenarios.
It is an excellent choice for mixed deployment of outdoor wireless coverage and outdoor surveillance.
The RG-RAP6262(G) supports three networking modes: gateway managed, MACC platform managed, and intelligent networking.
It can work with Reyee gateway, Reyee intelligent PoE switch, and Reyee access point to implement unified discovery, unified networking, unified configuration, and unified management.
In addition, it can be separated from hardware controllers to work with any vendor's routers or gateways, thus reducing the costs of network building or reconstruction.
The RG-RAP6262(G) also supports mesh networking, so access points can be easily deployed in the scenarios where wiring is not convenient.
Under the guidance of Reyee network app, you can launch and configure the devices on the entire network within three minutes.
You can locally or remotely manage the entire network devices by using app, web, Ruijie Cloud, or Reyee Routers, or share with others for assistance management.
This model does not include any power supply/PoE injector.
The device can be powered either a 802.3at PoE switch or injector, and has a power consumption of ?
18W.Compatible PoE Injectors can be found here: UltraLAN 52V 30W: https://shop.dbg.co.za/ul-poe-52-30w-g.htmlUbiquiti 48V 30W: https://shop.dbg.co.za/ub-poe-48g-30w.html
•802.11ac for up to 867 Mbps on the 5 GHz wireless data rate. •Ideal for long-range wireless transmission up to 1 km. •Auto-pairing and agile LEDs for efficient deployment. •3× Gigabit Ethernet ports for more high-speed IP camera connections. •Supports Omada SDN for remote and centralized management. •IP65 weatherproof enclosure and 6kV lightning protection ensure all-weather suitability. •Supports Passive PoE for flexible deployment (adapter included).
The RB-MAP (micro Access Point) by MikroTik RouterBOARD is a tiny sized 2.4GHz wireless Access Point with full RouterOS capabilities. It is portable, and accepts power from a wide variety of sources - USB, Passive or power jack.
Dual-radio mode: 2.4 GHz (2x2) + 5 GHz (2x2), providing a maximum rate of 575 Mbps and 1.2 Gbps, respectively, and a rate of up to 1.775 Gbps for the device
1 x GE electrical port
Automatically adjusts the coverage direction and signal strength based on the intelligent switchover algorithm. Such capability enables the AP to flexibly adapt to the application environment changes, providing accurate and stable coverage as STAs move
As the latest Wi Fi standard defined in IEEE 802.11, 802.11ax improves the user access capacity a nd bandwidth in high density access scenarios, reducing service latency and enhancing user experience.
802.11ax supports multi user multiple input multiple output (MU MIMO) on both the 2.4 GHz and 5 GHz frequency bands, allowing an AP to transmit data to a nd receive data from multiple STAs simultaneously and multiplying the utilization of radio spectrum resources.
802.11ax supports 1024 quadrature amplitude modulation (QAM), improving data transmission efficiency by 25% compared with 802.11ac (supporting 25 6 QAM).
Orthogonal frequency division multiple access (OFDMA) technology enables the AP to transmit data to multiple STAs at the same time using different subcarriers, reducing latency and improving network efficiency.
Spatial reuse (SR) technology uses ba sic service set (BSS) coloring to enable APs and STAs to distinguish overlapping BSSs, minimizing co channel interference.
