1000V 1-MPPT Combiner Box 12-In 1-Out 400A Isolator Type I & II SPD
Get registered and you will earn 322 points
(Each R100 spent = 1 point).Your cart will total 322 points.
This 1000V 1-MPPT Combiner Box efficiently combines 12 PV input pairs into 1 DC output for your solar installation. Designed for reliable performance, it features pre-fitted MC4 connectors and robust safety mechanisms.
- DC Isolation: Rated at 400A and 1000V for secure operation.
- Surge Protection: Equipped with Type 1 & 2 DC surge arrestors for sites experiencing frequent lightning strikes.
- Easy Connections: Includes pre-fitted MC4 connectors for inputs and outputs, plus a gland output for earthing.
IN STOCK at EXTERNAL supplier.
If ordered before 10AM:
DELIVERED 3-4 Days (main centres)
or 5-6 days (regional areas or large items)
COLLECTION from GeeWiz available in 3-4 Days
Streamline your solar setup with the 1000V 1-MPPT Combiner Box, engineered to safely combine 12 PV input pairs into a single DC output.
- Input/Output Configuration: Combines 12 PV input pairs into 1 DC output.
- Pre-Fitted Connectors: Inputs and outputs feature pre-fitted MC4 connectors.
- Earthing: Includes a dedicated gland output for earthing.
- DC Isolation: Rated at 400A and 1000V.
- Surge Protection: Features Type 1 & 2 DC surge arrestors, making it suitable for installation sites with frequent lightning strikes.
- Design Tool Compatibility: Can be assessed using the SegenSolar design tool to estimate strike rates based on postcode location for appropriate Type 1 or 2 protection recommendations.
- Fuse Note: Unit does not include DC fuses; compatible options include FUSE-20A-10x38 or FUSE-25A-10x38 to protect modules from high reverse current.
Ensure a professional and compliant setup by having this product installed by a qualified electrician or technician in accordance with local wiring regulations and standards.
