Shelly Pro 3EM (3-Phase Electricity Monitor) Relay With Three 120A Clamps

SHELLY PRO 3EM-120A
>Get registered and you will earn 34 points Get registered and you will earn 34 points (Each R100 spent = 1 point).
Your cart will total 34 points.

Next-generation DIN-mountable 3-Phase Energy Meter

Enhanced with all the gen2 firmware flexibility and LAN connectivity, the Shelly Pro 3EM-120 provides professional integrators with additional options for end-customer solutions. Shelly Pro 3EM-120 reports accumulated energy as well as instantaneous voltage, current, and power factor per phase in real-time.

  • Can measure up to 120A per phase and the neutral
  • 4 quadrant measurement with multiple connection types
  • Accuracy Class B active energy (Compliance with IEC 62053-21 based on manufacturer testing)
  • Photovoltaic ready
  • Phase sequence error detection (option)
  • Optical pulse indication of energy usage
  • Measurement accuracy tо 1%
  • Stores data in non-volatile memory that can be retrieved for a period of up to 60 days in 1-minute intervals
  • Package includes 3 pieces of 120A Current Transformers
R3,398 incl. VAT
R2,955 excl. VAT
FREE DELIVERY

IN STOCK at EXTERNAL supplier.
If ordered before 10AM:
DELIVERED in 2-3 business days (main centres)
or 5-7 business days (regional areas or large items)
COLLECTION from GeeWiz available in 2-3 business days

Or as low as R1,133 over 6 months interest-free, using your existing credit card. How it works

Volume discounts

Quantity Price You Save
5 R3,331 2%
30+ click to email

Quantity

Features

4-quadrant measurement

Measure capacitive and inductive load types of active imported and exported energies

Accuracy class B (active energy)

Shelly Pro 3EM has a measurement accuracy of 1%.

MODBUS support

Allows for easy and fast deployment in existing industrial installations..

Wi-Fi, LAN, and Bluetooth connectivity

Simultaneous Ethernet and Wi-Fi usage. MQTT, inbound and outbound WebSocket, UDP, mTLS support.

Power Monitoring

Monitors mono-phase electrical systems with up to 3 points simultaneously. Fast notifications and at least 60 days of 1-minute records storag

Scripting functionalities

Shelly Pro 3EM fully supports mjS scripting, allowing you to create further features and functionalities.

Diagrams

BASIC WIRING-DIAGRAM

SIMPLIFIED INTERNAL SCHEMATICS

Specifications

PHYSICAL
Size (HxWxD): 94x19x69 ±0.5 mm / 3.70x0.75x2.71 ±0.02 in
Weight: 62 ±1 g / 2.19 ±0.05 oz
Mounting: DIN rail
Screw terminals max torque: 0.4 Nm / 4.43 lbin
Conductor cross section: 0.5 to 2.5 mm² / 20 to 14 AWG (solid, stranded, and bootlace lugs)
Conductor stripped length: 6 to 7 mm / 0.24 to 0.28 in
Shell material: Plastic
Color: White
ENVIRONMENTAL
Ambient temperature: -20 °C to 40 °C / -5 °F to 105 °F
Humidity: 30 % to 70 % RH
Max. altitude: 2000 m / 6562 ft
ELECTRICAL
Power supply voltage AC: 110 - 240 V, 50/60 Hz
Power supply voltage DC: N/A
Power consumption: < 3 W
Sensors, meters
Temperature sensor: Yes
Voltmeters (RMS for each phase): 100 - 260 V
Voltmeters accuracy: ±1 %
Ammeters (RMS via CT for each phase and the Neutral): 0 - 120 A
Ammeters accuracy: ±1 % (2 - 120 A), ±2 % (1 - 2 A), ±5 % (0 - 1 A)
Power and energy meters: Active and apparent power, Active and apparent energy, Power factor, Fundamental active and fundamental reactive energy
No load threshold: 30 VA per phase
Measurement data storage: At least 60 days of 1 min data resolution
Data export: CSV for PQ recorded values JSON format export through RPC
RADIO
RF band: 2400 - 2495 MHz
Max. RF power: <20 dBm
Wi-Fi protocol: 802.11 b/g/n
Wi-Fi Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)
Bluetooth Protocol: 4.2
Bluetooth Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)
MCU
CPU: ESP32-D0WDQ6
Flash: 16 MB
FIRMWARE CAPABILITIES
Webhooks (URL actions): 20 with 5 URLs per hook
Scripting: mJS
MQTT: Yes
CoAP: No
