- 100mm rewindable submersible motor for standard applications with maintenance-free lubricated bearings and non-toxic vegetable oil.
- Dimensions and flange follow NEMA4 standards. Requires matching stairs control boxes or a USB control box.
Stairs Motor Submersible 100MM 7.5KW 400V
6009507834839
Get registered and you will earn 94 points
(Each R100 spent = 1 point).Your cart will total 94 points.
- 100mm rewindable submersible motor for standard applications with maintenance-free lubricated bearings and non-toxic vegetable oil.
- Dimensions and flange follow NEMA4 standards. Requires matching stairs control boxes or a USB control box.
R9,369 incl. VAT
R8,147 excl. VAT
+ R295.00 courier surcharge
IN STOCK at EXTERNAL supplier.
If ordered before 10AM:
DELIVERED 2-3 business days (main centres)
or 5-7 business days (regional areas or large items)
COLLECTION from GeeWiz available 2-3 business days (approx 4:30pm)
Product is expected to be in stock, however stock levels are LOW, so stock may be finished. If ordered, we will contact you if this product is sold out
Or as low as R3,123 over 6 months interest-free, using your existing credit card. How it works
100 mm Rewindable Submersible Motor For Standard Applications With Maintenance Free Lubricated Bearings And Approved Non-Toxic Vegetable Oil. Dimensions And Flange According To Nema4-Standards. Matching Stairs Control Boxes Must Be Installed Or A Usb Control Box. Maximum Water Temperature Of 35 degreesC And Immersion Depth Of 200 M. Motor Can Be Installed In A Horizontal Or Vertical Position. Motor Fitted With A Removable Lead-Out Cable. 0.37 Kw To 4 Kw. General Specifications: Mounting Flange: 4 Nema Standard; Insulation Class F; Protection Ip68; single phase Motors: 0.37 Kw Up To 4.0 Kw. Three-Phase Motors: 0.37 Kw Up To 7.5 Kw; Standard Voltages: 1 ~ 230 V (50 Hz); 3 ~ 230 V Or 400 V (50 Hz). Cable Length: 1.7 M - 0.37 Kw Up To 1.5 Kw; 2.5 M - 2.2 Kw Up To 7.5 Kw. Materials: Motor Shell - 304 Stainless Steel; Mechanical Seal - Ceramic/Carbon; Shaft (0.5 - 3 Hp) - 304 Stainless Steel; Shaft (4 -10 Hp) - 630 Stainless Steel.
