•Image Sensor 1/3” Progressive Scan CMOS
•Shutter Speed 1/3 to 1/10000 s
•Slow Shutter Yes
•Minimum Illumination Color: 0.005 Lux; 0 Lux with IR/white light
•Day/Night Mechanism IR Cut Filter
•Day/Night Switch Day/Night/Auto/Schedule-Switch
•4 mm: F1.6
•6 mm: F1.6
•Lens Mount M12
•Viewing Angle 2.8mm
•Horizontal FOV: 96.1°, Vertical FOV: 52°, Diagonal FOV: 113.6°
•Horizontal FOV: 49.3°, Vertical FOV: 26.8°, Diagonal FOV: 57.4°
•IR Working Distance 30m
•Illumination Distance 30 m
•Digital Noise Reduction 3D DNR
•Weatherproof Rating IP67
•Type Fixed Focal Lens
•Focal Length 2.8 mm/4 mm/6 mm
•Aperture 2.8 mm: F1.6
•4 mm: F1.6
•6 mm: F1.6
•FOV 2.8mm:
•Horizontal FOV: 96.1°, Vertical FOV: 52°, Diagonal FOV: 113.6°
•Horizontal FOV: 80°, Vertical FOV: 43.2°, Diagonal FOV: 94.2°
•Horizontal FOV: 49.3°, Vertical FOV: 26.8°, Diagonal FOV: 57.4°
•Lens Mount M12
•DORI Distance 2.8 mm
•Detect: 64 m (209 ft)
•Observe: 27 m (87 ft)
•Recognize: 13 m (42 ft)
•Identify: 6 m (21 ft)
•Detect: 80 m (262 ft)
•Observe: 33 m (109 ft)
•Recognize: 16 m (52 ft)
•Identify: 8 m (26 ft)
•Detect: 128 m (420 ft)
•Observe: 53 m (175 ft)
•Recognize: 26 m (84 ft)
•Identify: 13 m (42 ft)
•Max. Resolution 2560 X 1440
•Main Stream Frame Rate:
•50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
•Sub-Stream Frame Rate:
•50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
•60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
•Resolution:640x480, 352x288, 320x240
•Video Compression Main Stream: H.265+/H.265/H.264+/H.264
•Sub-Stream: H.265/H.264
•H.264 Type Main Profile/High Profile
•H.264+ Main Stream Supported
•H.265 Type Main Profile
•H.265+ Main Stream Supported
•Video Bit Rate Main Stream: 256 Kbps to 4 Mbps
•IR LED Quantity: 2
•Range: 30m
