Ubiquiti AirMax NanoBeam M5: 5GHz Hi Power 2×2 MIMO, 16dBi TDMA Station Wireless Antenna

Ubiquiti AirMax NanoBeam M5: 5GHz Hi Power 2×2 MIMO 16dBi TDMA Station Wireless Antenna

UBAM-NBEM5-16
>Earn 16 points/R16 Earn 16 points/R16 (Each R100 spent = 1 point, 1 point = R1 discount)
Your cart will total 16 points that can be converted into a voucher of R16.

• Uniform Beamwidth Improves Noise Immunity
• More Efficient Footprint
• Faster Processor Increases Performance
• Easy Assembly and Installation

R1,644 incl. VAT
R1,430 excl. VAT
FREE DELIVERY

IN STOCK at EXTERNAL supplier.
If ordered before 10AM:
DELIVERED next business day (main centres)
or 3-5 business days (regional areas or large items)
COLLECTION from GeeWiz available Same Day (approx 4:30pm)

Volume discounts

Quantity Price You Save
5 R1,612 2%
10 R1,579 4%
30+ click to email

Quantity

FEATURES

The new NanoBeam M has a compact, all-in-one design with uniform beam width, efficient footprint and a faster processor. The NanoBeam can be easily mounted in a variety of ways thanks to the innovative mechanical design.

Incorporating innovative industrial design with advanced technology, the NanoBeam®M is the latest generation of Ubiquiti Networks® airMAX® CPE for customer locations.

Innovative Mechanical Design
• All-in-one design: The NanoBeam provides both the radio and antenna in the smallest possible footprint.
• Quick and easy installation: No fasteners are required for pole-mounting, and a single wall fastener (not included) is required for wall-mounting.
• Convenient alignment: The NanoBeam pivots on its ball joint for easy aiming.

Compact Form Factor
• Efficient footprint: The radio and antenna are combined into a single body that takes up minimal space.
• Versatile mounting: The NanoBeam can be mounted in almost any position needed for line of sight.
• Aesthetics: The NanoBeam is small enough to blend discreetly into the background at a customer's location

PRODUCT SPECIFICATIONS

Manufacturer Ubiqiti Networks
Product Code UBAM-NBEM5-16
Processor Atheros MIPS 74KC, 560 MHz
Memory 64 MB DDR2, 8 MB Flash
Wireless Approvals FCC, IC, CE
Operating Frequency 5.725-5.875GHz
Gain 16dBi
Output Power 26 dBm
RoHS Compliance Yes
Power Supply 24V, 0.5A PoE
Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)
Max. Power Consumption  8W
Max. VSWR  1.5:1
 Wind Loading 10.2 lbf @ 125 mph
 Wind Survivability 125 mph
LEDs (1) Power, (1) LAN, (4) WLAN
Signal Strength LEDs  Software-Adjustable to Correspond to Custom RSSI Levels
Channel Sizes 5/8/10/20/30/40 MHz
Polarization Dual Linear
 Enclosure  Outdoor UV Stabilized Plastic
Mounting  Pole-Mount (Kit Included), Wall-Mount
ESD/EMP Protection Air: ±24 kV, Contact:± 24 kV
UBAM-NBEM5-16
